OUR SERVICES

PRECAST SHOP DRAWINGS

MARKING PLAN & ELEVATION

 Smart Draft Services delivers precise, easy-to-read panel & column shop drawings—every time. Whether it’s architectural, textured, colored, insulated, mesh, or concrete panels—if it’s concrete, we draft it. Our customizable drawings match your standards, making fabrication and installation smooth from start to finish.

MARKING PLAN & ELEVATION

MARKING PLAN & ELEVATION

 We ensures accurate models for precise shop drawings. Our clearly marked plans and elevations streamline installation and align with architectural specifications. We also optimize panel breakups where possible to help reduce precast costs.

PRECISION FITMENT TAKE-OFFS

  Stay ahead with accurate fitment take-offs—by panel, level, or project. From ferrules, cast in plates, grout tubes, dowel bars, props, stirrups, ligatures and face lifters to face edge lifters and more, we export directly from DWG to Excel for easy ordering and planning.

CONNECTION DETAILS

DOWEL & PROPPING DETAILS

 Connecting precast panels securely is crucial for building stability. There are many options available, and we can detail your proposed connections or suggest alternatives to the structural engineer. Avoiding welded connections can lead to significant cost savings on large projects.

DOWEL & PROPPING DETAILS

DOWEL & PROPPING DETAILS

DOWEL & PROPPING DETAILS

 Need a dowel layout or propping plan? We provide precise dowel locations from grid for starter bars and can adjust grout tube positions to match as-built conditions. While we don’t certify temporary works, we deliver detailed propping layouts for engineers to review.

CUSTOM FORMWORK

DOWEL & PROPPING DETAILS

DOWEL & PROPPING DETAILS

 Architects love curved, tapered, and textured designs, but these require custom CNC-cut formwork and special cast-in fitments. We can detail these panels and provide DWG/DXF files for your formwork supplier, including custom fitments for connections.

FORMLINER

FACADE PANELS

FACADE PANELS



 We also offer formliner design integration in our precast panel drawings upon request. Whether it’s a standard texture or a custom pattern, we can detail it accurately to ensure it’s ready for production.

FACADE PANELS

FACADE PANELS

FACADE PANELS



 We provide expert drafting for all types of precast façade panels—whether simple, curved, notched, colored, or form-liner. Our team ensures precise, detailed drawings to support efficient production and flawless installation.

WEATHER JOINT

FACADE PANELS



 We provide weather joints in precast panels, helping to protect against moisture ingress and ensuring the long-term durability of the building. These joints are detailed with precision to meet both functional and aesthetic requirements.

SMOOTH TRANSPORT & LIFTING

SMOOTH TRANSPORT & LIFTING



  At Smart Draft Services, we design panels with truck limits, city transport rules, and crane lifting capacity in mind—ensuring safe delivery, smooth handling, and hassle-free installation on site.
